Description
5.0 inch 480×854 sunlight readable TFT LCD display module | ST7701S controller | RGB interface TFT display | IPS full viewing angle LCD display module
This is a 5.0 inch TFT wide temperature LCD display with a resolution of 480×854 pixels. The display uses the ST7701S display driver IC and plug-in FPC for use with connectors. Its IPS technology provides full viewing angles and excellent color reproduction, ensuring distortion-free viewing from all angles. The display has a high contrast ratio of 1000:1, capable of presenting deep blacks and bright colors, and has a brightness of 500cd/m2, which is still clearly readable in sunlight. Supports 3.3V voltage and vertical screen display, FPC connection (optional connector). RGB conventional interface, strong data transmission capability, and moderate size make this display widely used in industrial manufacturing equipment.
This 5.0 inch TFT LCD display is vertically oriented. For this series of products, we also provide the capacitive touch version with optical bonding, TFT-H050A11FWIST5C20, and the ultra-high brightness model TFT-H050C09SVISTKC40 with a 5.0-inch horizontal display. If users want to find a low-power display that can be viewed in the sun outdoors, this TFT-H050A18SVRJDNN40 Transflective TFT will be your best choice. All displays can be customized with cover plates, FPCs, etc.
All materials meet environmental protection requirements and RoHS standards. This module is widely used in various instruments, smart devices, etc., and is suitable for a variety of microcontroller development platforms such as STM32, 8051, PIC, AVR, ARDUINO, ARM, and Raspberry Pi.
